Arduino mega 2560 pins serial#

It communicates using the original STK500 protocol ( reference, C header files). The ATmega2560 on the Mega 2560 comes preprogrammed with a bootloader that allows you to upload new code to it without the use of an external hardware programmer. For details, see the reference and tutorials.

The Mega 2560 board can be programmed with the Arduino Software (IDE).

On the Product itself through Arduino Customer SupportĪrduino Mega 2560 is open-source hardware! You can build your own board using the follwing files:.

You can find in the Getting Started section all the information you need to configure your board, use the Arduino Software (IDE), and start tinker with coding and electronics. You can find your board warranty information here. The Mega 2560 is an update to the Arduino Mega, which it replaces. The Mega 2560 board is compatible with most shields designed for the Uno and the former boards Duemilanove or Diecimila. It contains everything needed to support the microcontroller simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started.

Arduino mega 2560 pins serial#

It has 54 digital input/output pins (of which 15 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. The Arduino Mega 2560 is a microcontroller board based on the ATmega2560. With 54 digital I/O pins, 16 analog inputs and a larger space for your sketch it is the recommended board for 3D printers and robotics projects. The MEGA 2560 is designed for more complex projects.
